GE DS3800HPIB panel interface board
GE DS3800HPIB
1. Overview
The GE DS3800HPIB is part of the Speedtronic Mark IV series and is a panel interface board used for connecting and controlling industrial equipment. It supports multiple communication protocols, including HPIB (IEEE-488), Ethernet, and DeviceNet, enabling high-speed data transmission and efficient communication between devices. This module has high reliability and flexibility, and is suitable for complex industrial environments.
2. Parameters
Communication interface: HPIB（IEEE-488）， The maximum communication rate is 1.5 MB/s; RS-485 interface, with a maximum communication rate of 9600 bps.
Power supply voltage:+ 5 VDC ± 5%, power consumption is 2 W.
Working temperature range: -10 ℃ to 60 ℃.
Storage capacity: Contains approximately 45 EPROMs and EEPROMs for storing programming information.
Size: 19.0 x 14.5 x 7.0 inches.
Weight: 25 pounds.
3. Product features
High performance: Supports high-speed data transmission and real-time control, suitable for complex industrial applications.
Multifunctionality: Supports multiple input/output ports, including digital input/output, analog input/output, etc.
Usability: Provide detailed user manuals for easy installation and configuration.
Reliability: Built in diagnostic function ensures reliable operation and simplifies troubleshooting.
Compatibility: It can be networked with various industrial equipment (such as PLC, DCS, HMI, etc.) and supports a wide range of application scenarios.
4. Structure and composition
Circuit board design: A large circuit board with eight connection terminals of different sizes on both sides.
Component composition:
Approximately 50 sky blue small diodes and 6 silver diodes.
36 LED light-emitting diodes used to indicate specific functions.
45 EPROM and EEPROM modules for storing programs.
Approximately 45 light blue resistors, each with a unique color stripe.
Appearance features: There is a small red square in the lower left corner with a toggle switch.
5. Application Fields
GE DS3800HPIB is widely used in the following fields:
Industrial automation: used for controlling machinery, processes, and equipment.
Process control: suitable for DCS systems, PLC programmable control systems, etc.
Energy industry: such as thermal power plant monitoring systems, intelligent steel open hearth systems, etc.
Transportation and medical fields: supporting the connection and control of various industrial equipment.
Other applications: including petrochemicals, manufacturing, rail transit, etc
