The GE 750-P5-G1-S1-LO-A1-R-E 750 Feeder Protection Relay is a sophisticated electronic device designed to protect electrical feeders from various faults and abnormal conditions.

It is a crucial component in power distribution systems, ensuring the safety and reliability of electrical supply.

Key Features and Functions:

1. Overcurrent Protection: Detects excessive current flow in the feeder and initiates appropriate protective actions to prevent equipment damage or fire.

2. Phase Balance Protection: Monitors the balance between the three phases of the feeder and triggers alarms or protective actions if there is an imbalance, indicating a potential fault.

3. Ground Fault Protection: Detects abnormal current flow to ground and initiates protective measures to isolate the faulty equipment and prevent electrical shock or fire hazards.

4. Directional Overcurrent Protection: Determines the direction of current flow and initiates protective actions only for faults occurring in the protected zone.

5. Loss of Power Protection: Detects a loss of power supply to the feeder and initiates appropriate actions, such as transferring the load to a backup source or activating emergency lighting.

6. Underfrequency Protection: Detects a decrease in system frequency below a predetermined threshold and initiates protective actions to prevent system instability.

7. Overfrequency Protection: Detects an increase in system frequency above a predetermined threshold and initiates protective actions to prevent damage to equipment.

8. Remote Control and Monitoring: Provides remote control and monitoring capabilities, allowing operators to control the relay’s functions and monitor its status from a central location.
